Pressure Transmitter Model S 10
₨ 19,500
MarshallTown Transmitter Model: S-10 has a very high quality silicon sensor which makes all the difference when accuracy is your concern. High precision and excellent repeatability make perssure transmitter to be the best choice for precision demanding applications. This robust transmitter with Zero & Span adjustment screw and 0.25% BFSL accuracy is the best choice to combine with KIPINAGO diaphragm seals. Two special features of polarity protection and anti-jamming circuits are embedded in every MarshallTown Pressure Transmitter.
Description
Applications
- Sensitive Industrial Applications
- Severe Industrial environments demanding a better ingress protection
- Process Automation
Special Features
- Strong structure and material
- Polarity protection and anti-jamming circuit
- High accuracy and precision
| Feature | Detail | Application |
| Measuring Range: | -1 to 1000 Bar | Chemical, Petrochemical Industry |
| Output: | 4-20 mAp | Oil, Natural gas |
| Connection: | 1/2″ NPT | Machine Building |
Additional information
| Ranges | -1 +1, -1 +1 Bar, -1 +10 Bar, -1 +3 Bar, -1 +5 Bar, 1 BAR, 10 BAR, 100 BAR, 100 mbar, 100 PSI / 7 bar, 1000 BAR, 1000 mbar, 150, 150 BAR, 16 BAR, 160 mbat, 160 PSI / 11 bar, 2.5 BAR, 200 PSI / 14 bar, 25 BAR, 25 mbar, 250, 250 BAR, 250 mbar, 40 BAR, 40 mbar, 400 BAR, 400 mbar, 60 Bar, 60 mbar, 7 BAR, 70 BAR, 700 BAR, VACUM – 760mmhg, VACUM -760MMG |
|---|
