Vortex Flow Meter
Application:
The Vortex Flow Meter is used for measuring the flow rate of liquids, gases, and steam in pipes. It is commonly used in industries such as oil and gas, chemical processing, and power generation. It is a reliable and accurate flow measurement solution that is suitable for applications where high-temperature, high-pressure, or corrosive fluids are present. It is also commonly used for measuring flow in applications that require low maintenance and minimal pressure loss.
Description
| Parameter | Description |
|---|---|
| Type: | Vortex Shedding Flow Meter |
| Measuring Principle: | Vortex Shedding |
| Body Material: | Stainless Steel, Carbon Steel, or PVC |
| Measuring Range: | 1 to 12000 m3/h |
| Pipe Size: | 15mm to 6000mm |
| Accuracy: | ±1% to ±1.5% of reading |
| Repeatability: | ±0.25% to ±0.5% |
| Pressure Rating: | Up to 40 bar |
| Temperature Range: | -40°C to 250°C (-40°F to 482°F) |
| Output: | Pulse, Analog (4-20mA), or digital (HART, Modbus, etc.) |
| Power Supply: | DC or AC power |
| Display: | LCD display for flow rate and total flow |
| Turndown Ratio: | 10:1 to 100:1 |
| Mounting: | Flanged, Wafer, or Threaded |
| Wetted Parts: | Stainless Steel or PTFE |
| Protection Rating: | IP65 to IP68 |
| Weight: | 1 to 20 kg (2.2 to 44 lb) |
